CroqTile
The Next-Gen GPU & DSA Language Achieves 5x Productivity
CroqTile Intro Video
Replay
CroqTile
|
Overview
What is CroqTile?
The most easy-to-use kernel programming language
Simplicity + Performance
Compile-Time Safety
Heterogeneous Computing
Born for AI Agents
Chapter 1
Highlight 1: Simplicity + Performance
Best of all competitors: Triton / CuTe / Cutile / Helion
CroqTile
|
Chapter 1 — GPU MatMul Anatomy
Demo: Tiled MatMul with Tensor Core & TMA in CroqTile
CroqTile
|
Chapter 1 — Simplicity + Performance
Simplicity + Performance
The most intuitive GPU & DSA programming language among all competitors
Least LoC for the same kernel among all competitors
40% of equivalent CUDA code — higher abstraction than Triton
CroqTile
|
Chapter 1 — Simplicity + Performance
Why CroqTile Is So Simple & Intuitive
It operates on Tensors - Easy for programming.
It fully supports low-level programming - Without sacrificing safety.
CroqTile: shape + coord + stride is the complete tensor interface — no raw pointers or manual layout math exposed
Triton: pointer + shape + stride + offset per tensor via
make_block_ptrCuTe: Layout = Shape + Stride — compose hierarchical layouts manually
CUDA: raw pointer + manual index arithmetic at every access
| Exposed to user | CroqTile | Triton | TileLang | CuTe | CUDA |
|---|---|---|---|---|---|
| Shape | ✓ | ✓ | ✓ | ✓ | ✓ |
| Coord | ✓ | ✓ | ✓ | ✓ | ✓ |
| Stride | ✓ | ✓ | — | ✓ | ✓ |
| Layout | — | — | — | ✓ | — |
| Offset | — | ✓ | — | — | ✓ |
| Raw pointer | — | ✓ | — | ✓ | ✓ |
Data movement is one line — hardware details are hidden
One-line TMA/DMA:
tma.copy.swiz<128> src => dst — load or store a tileCompiler generates TMA descriptor setup (128 bytes, 10+ fields in CUDA)
No manual
CUtensorMap creation, no host-side cuTensorMapEncodeTiledZero boilerplate — optimization via modifiers, not code rewrites
Swizzle, cache promotion, zfill, async pipeline — all one keyword
Lines of code — TMA load + store
One semantic for all tensor core instructions — compiler picks the best
Complete MMA cycle in 5 lines: fill, load×2, compute, store
Encapsulates WGMMA descriptor — no manual register layout or fence
Compile-time dispatch: HMMA (SM70/80) vs WGMMA (SM90) — zero runtime overhead
Lines of code — MMA operations
Sparsity is a modifier, not a rewrite — add .sp and you’re done
mma.row.row.sp — single modifier adds 2:4 structured sparsityMetadata prepack + warp shuffle handled implicitly by compiler
Triton: not supported. CUDA: 30 LOC metadata handling
Lines of code — metadata handling only
One keyword for all parallelism — block, warp-group, thread, multi-device
Unified
parallel-by — one keyword for all parallelism levelsLevel specifiers (
block, group-4, thread) map to GPU & DSA hardwareSame code targets NVIDIA, AMD, and custom accelerators
Parallelism primitives needed
Every optimization pattern is a first-class construct — zero boilerplate
Each pattern is 1–3 change sites — structural changes localized
Persistent kernel: change
parallel binding + add tile loopWarp spec: wrap in
inthreads.async — inner code unchangedPipeline: add
shared event + wait/triggerMinimal change sites → easy for both humans and AI to apply
AI can iterate 68 times in one session (see AI-Tuning slides)
Each optimization is additive, not a rewrite
CroqTile
|
Chapter 1 — Simplicity + Performance
Zero-Cost Abstraction
CroqTile matches highly-optimized vendor libraries — higher-level syntax, near-zero performance gap
Kernel-Level Performance
Standalone kernel throughput (TFLOPS, higher is better) — CroqTile vs vendor libraries (Hopper)
End-to-End: Qwen3.5 on SGLang
CroqTile kernels integrated into SGLang — Hopper GPU
Qwen3.5 27B (BF16, Hopper ×1)
| Metric | CroqTile | Native | Ratio |
|---|---|---|---|
| Prefill (ktokens/s) | 5,498 | 6,200 | 88.7% |
| Decode (tokens/s) | 26 | 28 | 92.9% |
Qwen3.5 27B (FP8, Hopper ×1)
| Metric | CroqTile | Native | Ratio |
|---|---|---|---|
| Prefill (ktokens/s) | 6,500 | 7,400 | 87.8% |
| Decode (tokens/s) | 37 | 39 | 94.9% |
Why Zero-Cost?
✓
CroqTile kernels competitive with highly-optimized vendor libraries (cuSparseLt, CUTLASS, PyTorch)
✓
No runtime overhead — static dispatch, no vtable, no interpreter
✓
End-to-end performance within 5% of native serving — with far simpler code
Chapter 2
Highlight 2: Compile-Time Code Safety
Best of all competitors: Triton / CuTe / Cutile / Helion
CroqTile
|
Chapter 2 — Compile-Time Safety
Why Compile-Time Checking Matters
GPU bugs are silent — wrong shapes or OOB reads produce garbage output, not crashes. No stack trace, no debugger for 10k threads.
CroqTile catches them at compile time — exact file, line, and root cause before any GPU execution.
Why? A standalone compiler (not a Python DSL) owns the full program — shapes, types, and memory hierarchy are statically visible across all passes.
CroqTile
|
Chapter 2 — Compile-Time Safety
Compile-Time Checks to Prevent Runtime Errors
Shape / type mismatch — incompatible ranks or element types in DMA/MMA
Out-of-bounds access — static offset/index analysis catches overruns
HW constraint violation — MMA config vs. target SM architecture
Unwait-ed async — futures never consumed are flagged
Parallel nesting rules — illegal constructs at wrong parallel level
In CUDA — all are silent runtime bugs
No crash, no warning — just wrong numbers or rare hangs.
CroqTile
|
Chapter 2 — Compile-Time Safety
Auto-Generated Runtime Assertions
When dynamic dimensions are involved, the compiler auto-generates host-side assertions — catching errors before GPU dispatch
Cross-parameter shape — shared dims (
K in lhs[M,K], rhs[K,N]) must match
Static shape constants — actual shapes vs. declared values
Memory budget — cumulative allocation vs. HW limits
Tiling & iteration space — bounds > 0, non-degenerate strides
Dynamic index bounds — element indices within dimension when only known at launch
Launch limits — thread/grid products respect SM-specific maximums
In CUDA — no safety net
These errors produce silent wrong results, hangs, or UB.
Chapter 3
Highlight 3: Support for Heterogeneous Computing
Write once, run everywhere — GPU, AMD, DSA & multi-device
CroqTile
|
Chapter 3 — Heterogeneous Computing
Same Language, Multiple Targets.
-t cute -arch=sm_90a
→
NVIDIA H800 / H100
Hopper SM90a (PTX + SASS)
-t cute -arch=sm_80
→
NVIDIA A100
Ampere SM80 (PTX + SASS)
-t hip -arch=gfx1030
→
AMD Radeon RX 6900 XT
RDNA2 · gfx1030
-t dsa_x -arch dsa_arch_y
→
Custom DSA
Pluggable backend architecture
Myth: The compiler lowers CroqTile IR to each backend's native ISA. Minor changes are required.
CroqTile
|
Chapter 3 — Heterogeneous Computing
Multi-Device Programming
matmul [M, N] → partitioned by parallel-by mpi
Node (0,0)
M[0:M/2] × N[0:N/2]
GPU 0 · block kernel
Node (0,1)
M[0:M/2] × N[N/2:N]
GPU 1 · block kernel
Node (1,0)
M[M/2:M] × N[0:N/2]
GPU 2 · block kernel
Node (1,1)
M[M/2:M] × N[N/2:N]
GPU 3 · block kernel
Few boilerplate for heterogeneous computing:
• Kernel launch — compiler generates host dispatch
• Type conversion & alignments — handled automatically
• Data partitioning —
• Kernel launch — compiler generates host dispatch
• Type conversion & alignments — handled automatically
• Data partitioning —
parallel-by mpi splits work across ranks
Chapter 4
Highlight 4: Born for Agentic AI Programming
Superior context engineering + superior harness engineering
CroqTile
|
Chapter 4 — AI Programming
AI Tuning Convergence Comparison NVIDIA H800 PCIe · Template-Free · Same Agent
Same AI agent, same hardware, same budget.
Only the language (DSL) changes.
Only the language (DSL) changes.
matmul FP16→FP32 · 16384³
486
CroqTile
384
Triton
343
TileLang
318
Helion
162
CUDA
27
CuTe-DSL
cuBLAS baseline: 420 TFLOPS · CroqTile = 115% of vendor
Blockscale GEMM E4M3→FP32 · 8192³
711
CroqTile
408
TileLang
298
Triton
167
Helion
cuBLAS baseline: 460 TFLOPS · CroqTile = 155% of vendor library · 6 iterations only
matmul FP16→FP32 · 16384×16384×512
360
CroqTile
355
Triton
288
Helion
260
TileLang
169
CUDA
cuBLAS baseline: 403 TFLOPS · thin-K shape (memory-bound)
matmul FP16→FP32 · 16416³ (non-aligned)
345
Triton
330
Helion
329
TileLang
300
CroqTile
160
CUDA
cuBLAS baseline: 413 TFLOPS · non-power-of-2 shape (ongoing tuning)
Y-axis = running-best TFLOPS, dashed line = cuBLAS baseline.
CroqTile
|
Chapter 4 — AI Tuning Results
CroqTile + AI-Tuning = Production-Level Performance
CroqTile AI-tuned wins 84% of 95 shapes.
Average speedup +16.7% over cuSPARSELt.
CroqTile
|
Chapter 4 — AI Programming
Why CroqTile Fits AI Tuning
Same persistent warp-specialized GEMM — measured token count
CroqTile
36 LOC / 303 tokens
Triton
80 LOC / 449 tokens
CUDA + CuTe
182 LOC / 1530 tokens
CUTLASS
280 LOC / 2350 tokens
303
CroqTile
449
Triton
1530
CUDA+CuTe
2350
CUTLASS
Implication: for the same 100 iterations, CroqTile uses ~70K tokens while CUDA uses ~350K. CroqTile can run 5× more iterations, or use a smaller model.
CroqTile: the same DMA transfer = 1 line of code & the compiler generates the barrier
✔
Buffer =
shared f16 [M, K] lhs_s;
✔
DMA = tma.copy.swiz<128> src => lhs_s;
✔
Barrier / fence = inserted automatically by the compiler
AI tuning actions → code-change count comparison
Change tile size (WARP_M/N)
1 site
5 sites
Change swizzle mode
1 site
3 sites
Change pipeline stages
1 site
4 sites
Change data type (f16→f8)
1 site
7 sites
Add warp specialization
2 sites
6 sites
CroqTile / CUDA
CUDA: errors appear only at runtime
⚠
Tile is not divisible → device hang
⚠
Shared memory limit exceeded → silent launch failure
⚠
Swizzle mismatch → wrong results
⚠
mbarrier error → deadlock
CroqTile: full compile-time diagnostics
✔
error: tile M=96 not divisible by WARP_M=64
✔
error: smem 49408B exceeds 48KB limit
✔
error: swiz<128> requires 128B-aligned
✔
error: mma.row requires M%64==0
353
compile checks
1,319
runtime asserts
3–8s
CroqTile / iteration
30–90s
CUDA / iteration
Thank You!!
CroqTile — Fewer Lines. Safer Kernels. AI-Native.
Main Repository
github.com/LancerLab/croqtile
A Next-Gen Kernel Programming DSL for Maximizing Productivity
