Croqtile-C++ Program Structure

Overview

In this section, we will introduce the fundamental structure of Choreo-C++ programs and their associated terminology. Additionally, we will present a parallel element-wise addition Choreo-C++ program to demonstrate how Choreo simplifies data orchestration across heterogeneous hardware.

Construct a Choreo-C++ Program

A typical Choreo-C++ program is composed of multiple parts, depending on the target platform. For a Choreo-supported platform, which is usually a programming environment leveraging heterogeneous parallel hardware, the Choreo-C++ program typically contains three parts:

  • The Device Program
  • The Host Program
  • The Tileflow Program

Host, Device and Tileflow

The code below showcases a Choreo-C++ program targeting CUDA/Cute:

// Device program: typically runs on GPU/NPU
__device__ void device_function(...) {
  // High-performance device kernel implementation
}

// Tileflow program: orchestrating data movement
__co__ void choreo_function(...) {
  // ... choreo code ...
  device_function(...);
  // ...
}

// Host program: typically runs on CPU
void main() {
  // ... prepare data ...
  choreo_function(...);
  // ...
}

Let's briefly review each part:

Host Program

The Host Program serves as the entry point of the Choreo-C++ module/program and is the caller of the Tileflow Program (Choreo Functions). Written in standard C++, it runs on the CPU and manages the overall workflow of the heterogeneous application.

In a simple high-performance kernel implementation, programmers typically prepare the necessary data in the host program to invoke Choreo functions and handel their return values to advance further steps.

Device Program

The Device Program defines computation-intensive operations executed on the target device. In the example above, the device function is prefixed with __device__, which is an keyword from CUDA/Cute, indicating it runs exclusively on the heterogeneous device. Similar to the host program, any device program is not altered in Choreo compilation process.

Tileflow Program

Those familiar with CUDA/Cute may already be acquainted with host programs and device programs. However, the Tileflow Program, composed of Choreo functions (prefixed with __co__), is the core of Choreo-C++ programs. It orchestrates data movement among different hosts/devices and among different storage levels within a single device. In a typical workflow, the Tileflow program moves data to an appropriate storage location (as buffer) and calls device programs to perform computations. Once the work is complete, it moves the results back to the host.

Transpilation and Compilation

The Choreo compilation process typically involves three major steps: Pre-processing, Transpilation, and Target Compilation. To better understand how different parts of a Choreo-C++ program work together, the full compilation workflow is illustrated below:

Choreo-Workflow

As shown in the figure, immediately after pre-processing, Choreo transpiles (source-to-source compilation) the tileflow program into target code, leaving the user-provided host program and device program unchanged. The tileflow program is transpiled into host and device source code, which we refer to as choreo-generated code. The compiler then combines the user-provided code and choreo-generated code to perform the target compilation process. This process can generate various outputs, such as transpiled source code, workscripts, target modules, target assembly, and executables.

Thus, the Choreo compiler functions as a end-to-end compiler, with the key step being the transpilation of the tileflow program into choreo-generated code.

One notable feature of Choreo compilation is its support for both:

  • Single Source Compilation Model: Similar to CUDA/Cute, where the target compiler allows device and host programs to be in a single source file for target compilation.
  • Separate Source Compilation Model: Similar to OpenCL, where host and device code must be compiled separately.

The code shown above naturally supports the Single Source Compilation Model. However, to support the Separate Source Compilation Model, Choreo requires wrapping the Device Program with the __cok__ block, as shown below:

__cok__ {
  void device_function(...) { ... }
} // end of __cok__

__co__ void choreo_function(...) { ... }

void foo() { ... }

This is the code structure for a Choreo-OpenCL C++ program. The OpenCL compiler requires the device program (device_function in the code) to be stored in a separate file from the host program. The __cok__ {} wrapper enables the Choreo compiler to handle user-provided device code properly. It helps Choreo separate device and host code from a single Choreo source file for different compilation processes. Therefore, do not be surprised if you encounter __cok__ in certain Choreo code; it is necessary for integrating support for the Separate Source Compilation Model.

A Full Choreo-Cute C++ Code Example

Below is a complete Choreo-Cute C++ code example that performs element-wise addition on two arrays of the same size and element type:

// Device Program
__device__ void kernel(int * a, int * b, int * c, int n) {
  for (int i = 0; i < n; ++i) c[i] = a[i] + b[i];
}

// Tileflow Program
__co__ s32 [6, 17, 128] ele_add(s32 [6, 17, 128] lhs, s32 [6, 17, 128] rhs) {
  s32 [lhs.span] output; // Use same shape as lhs

  // first `parallel` indicates the kernel launch
  parallel p by 6 {
    with index in [17, 4] { // Tiling factors
      foreach index {
        lhs_load = dma.copy lhs.chunkat(p, index) => local;
        rhs_load = dma.copy rhs.chunkat(p, index) => local;

        local s32 [lhs_load.span] l1_out;

        // Call kernel with loaded data
        call kernel(lhs_load.data, rhs_load.data, l1_out, |lhs_load.span|);

        // Store result back to output
        dma.copy l1_out => output.chunkat(p, index);
      }
    }
  }
  return output;
}

// Host Program
int main() {
  // Define data arrays
  choreo::s32 a[6][17][128] = {0};
  choreo::s32 b[6][17][128] = {0};

  // Fill arrays with data
  std::fill_n(&a[0][0][0], sizeof(a) / sizeof(a[0][0][0]), 1);
  std::fill_n(&b[0][0][0], sizeof(b) / sizeof(b[0][0][0]), 2);

  // Call Choreo function (data movement and device kernel execution)
  auto res = ele_add(choreo::make_spanview<3>(&a[0][0][0], {6, 17, 128}),
                     choreo::make_spanview<3>(&b[0][0][0], {6, 17, 128}));

  // Verification: check correctness of results
  for (size_t i = 0; i < res.shape()[0]; ++i)
    for (size_t j = 0; j < res.shape()[1]; ++j)
      for (size_t k = 0; k < res.shape()[2]; ++k)
        if (a[i][j][k] + b[i][j][k] != res[i][j][k]) {
          std::cerr << "result does not match.\n";
          abort();
        }

  std::cout << "Test Passed\n" << std::endl;
}

The subsequent sections will explain the different parts of the code.

Host Program - the Control Center

As introduced, the host program serves as the entry point of the Choreo-C++ program and acts as the control center. For convenience, here is the code again:

int main() {
  // Define data arrays
  choreo::s32 a[6][17][128] = {0};
  choreo::s32 b[6][17][128] = {0};

  // Fill arrays with data
  std::fill_n(&a[0][0][0], sizeof(a) / sizeof(a[0][0][0]), 1);
  std::fill_n(&b[0][0][0], sizeof(b) / sizeof(b[0][0][0]), 2);

  // Call Choreo function (data movement and device kernel execution)
  auto res = ele_add(choreo::make_spanview<3>(&a[0][0][0], {6, 17, 128}),
                     choreo::make_spanview<3>(&b[0][0][0], {6, 17, 128}));

  // Verification: check correctness of results
  for (size_t i = 0; i < res.shape()[0]; ++i)
    for (size_t j = 0; j < res.shape()[1]; ++j)
      for (size_t k = 0; k < res.shape()[2]; ++k)
        if (a[i][j][k] + b[i][j][k] != res[i][j][k]) {
          std::cerr << "result does not match.\n";
          abort();
        }

  std::cout << "Test Passed\n" << std::endl;
}

The main function is written with standard C++, except for the use of Choreo APIs. In this program, we first define two arrays, a and b, and fill them with different values. The API choreo::make_spanview is then used to attach shape information to the data.

The choreo::make_spanview is declared as follows:

template <size_t Rank, typename T>
spanned_view<T, Rank> make_spanview(T* ptr, std::initializer_list<size_t> init);

Here is the usage for reference:

choreo::make_spanview<3>(&a[0][0][0], {6, 17, 128});

This API is essential for connecting host code to the choreo functions. Essentially, any input buffer (named the spanned data) of choreo function is always associated with its shape. It enables Choreo to guarantee shape safety at compile and runtime.

Note: The most significant dimension value comes first in the initializer_list shape. Thus, a shape of {6, 17, 128} corresponds to a C multi-dimensional array like a[6][17][128].

In the example code, choreo function ele_add is called to calculate the element-wise sum in parallel. Afterward, the host code verifies the result buffer res.

One important detail is that the output of the choreo function is of type choreo::spanned_data. Unlike choreo::spanned_view, which does not own the buffer memory of the data it points to, choreo::spanned_data owns the buffer. This ensures that the subsequent data verification process is applied to valid memory. The choreo::spanned_view provides rich APIs, supporting C-style array indexing and shape queries via the member function .shape().

Similarly, the most significant dimension is listed first in this shape array (res.shape()[0] in this case). Choreo follows a 'most-significant-dimension-major' ordering, also known as 'row-major' ordering, where the first dimension varies the slowest.

Device Program: Parallel Computation

The device program defines the computational kernel that will be executed on the target device such as a GPU. The kernel is designed to operate on input data, process it in parallel, and generate the output.

We repeat the code as below:

__device__ void kernel(int * a, int * b, int * c, int n) {
  for (int i = 0; i < n; ++i) c[i] = a[i] + b[i];
}

For targets that only support the Separated Source Programming Model, the code may need to be wrapped within a __cok__ {} block. The equivalent Choreo-OpenCL C++ code is shown below:

__cok__ {
  extern "C" void kernel(int * a, int * b, int * c, int n) {
    for (int i = 0; i < n; ++i) c[i] = a[i] + b[i];
  }
} // end of __cok__

Here, the extern "C" annotation replaces the __device__ keyword used in CUDA/Cute target, as OpenCL requires C-linkage for the device functions.

Choreo's device programming model varies depending on the target hardware and its supported features. For example, some private targets allows the use of vectorizing programming interfaces, or intrinsic function to fully leverage the computational power of the parallel target hardware.

Programmers must be aware that the device program follows the Single-Program-Multiple-Data (SPMD) paradigm. In this paradigm, multiple instances of the same device program are executed in parallel, making it highly efficient for exploiting data-level parallelism on target hardware. However, unlike traditional CUDA/Cute programs, the device program does not manage data movement —whether between the host and device or across multiple storage levels within the device. Instead, the tileflow program orchestrates these tasks in a much simpler and safer manner.

Tileflow Program: Orchestrating the Data Movement

The Tileflow Program consists of Choreo functions. As described earlier, it manages the movement of data between the host and the target device, ensuring that data is copied correctly across different storage locations.

For convenience, let’s revisit the code:

__co__ s32 [6, 17, 128] ele_add(s32 [6, 17, 128] lhs, s32 [6, 17, 128] rhs) {
  s32 [lhs.span] output; // Use same shape as lhs

  // first `parallel` indicates the kernel launch
  parallel p by 6 {
    with index in [17, 4] { // Tiling factors
      foreach index {
        lhs_load = dma.copy lhs.chunkat(p, index) => local;
        rhs_load = dma.copy rhs.chunkat(p, index) => local;

        local s32 [lhs_load.span] l1_out;

        // Call kernel with loaded data
        call kernel(lhs_load.data, rhs_load.data, l1_out, |lhs_load.span|);

        // Store result back to output
        dma.copy l1_out => output.chunkat(p, index);
      }
    }
  }
  return output;
}

In this code, the __co__-prefixed choreo function accepts two inputs lhs and rhs, both with the shape [6, 17, 128] and the element type of s32 (signed 32-bit integer). And the output is defined to have the same shape and type as the inputs.

The parallel p by 6 {...} block indicates that the enclosed code runs in parallel. Specifically, six instances of the code are executed concurrently. This implies a transition in the execution environment from the host to the device. For those familiar with CUDA, this concept is analogous to a kernel launch, where multiple threads or processes are initiated to perform computations simultaneously on the device.

Inside the parallel-by block, a with-in block binds the symbol index to two values, 17 and 4. In Choreo, index is referred to as a bounded-ituple with two bounded values, which can be used in foreach statements. (We will explain bounded types in later chapters.)

The foreach index {...} statement is equivalent to the following C code:

for (int x = 0; x < 17; x++)  // assume 'x' represents the 1st element of 'index'
  for (int y = 0; y < 4; y++) { ... }  // and 'y' represents the 2nd element of 'index'

Within the foreach block, the dma.copy statement describes how data movement occurs. For example, consider the statement lhs_load = dma.copy lhs.chunkat(p, index) => local;:

  • The symbol lhs_load is called future of the DMA operation, which contains information about the DMA destination.
  • dma.copy invokes a direct DMA data transfer without transforming the shape of the data. The expression on the left-hand side of => represents the DMA source, while the right-hand side represents the destination.
  • In this case, the destination is specified as a local buffer, which is automatically allocated by the Choreo compiler.
  • The source expression lhs.chunkat(p, index) is referred to as the chunkat expression in Choreo. Here, p and index tiling factors for the lhs. Given that lhs has a shape of [6, 17, 128] and the upper bounds of p and index are 6, 17, and 4, the data chunk size is 1x1x32 (6/6, 17/17, 128/4). In each iteration, a single data chunk is used as the source, with the exact chunk determined by the current values of p and index. For example, in parallel thread 1 and the iteration {16, 2}, the chunk's offset is set to {1, 16, 2}.

This is illustrated in the below figure:

Choreo-Structure-Chunkat

With the DMA statement, different chunks of data tiled from lhs are moved iteratively and in parallel from the host to the device's local memory. Similarly, the DMA statement manages rhs by moving it in small chunks to local memory for processing.

Next, the statement local s32 [lhs_load.span] l1_out; defines a per-parallel-thread buffer. Note here it takes its shape from the expression lhs_load.span, which represents the tiled block. The buffer is used to store the output data in the subsequent call statement. The call statement invoke the device function named kernel to perform computations. Once the computation is complete, another DMA statement moves the output data from the local buffer back to host. This complete one iteration.

In this code, each parallel thread runs 17x4 iterations, with each iteration handling a 1x1x32-sized chunk of data. The choreo program terminates when all 6 parallel threads have completed their iterations. It then returns the output buffer to its caller, the host program.

Quick Summary

You are now aware that a Choreo-C++ program consists of three parts, with the tileflow program being the core. This part is transpiled into target source code during the compilation process. The call chain typically flows from the host to the tileflow program, and then from the tileflow program to the device code.

You may have noticed that Choreo not only abstracts DMA operations into higher-level semantics but also combines iteration and tiling for ease of use. This makes Choreo code concise and expressive. In the following chapters, we will delve deeper into Choreo's syntax and semantics to explore its full potential.
